TT-SATC steam aging test chamber for IEC 60068 steam aging tests: three SUS304 sample drawers, steam temperature from room temperature +5 °C to 98 °C at ≥95 % RH, PID control with PT100 sensor, timer from 1 s to 9999 h, and over-temperature, leakage and water-shortage protections.
TT-AHHT-100 hydrostatic head tester for AATCC 127 and ISO 811 fabric waterproofness testing: 0–100 kPa range with ±0.2 % accuracy, 100 cm² clamp area, selectable Pa/kPa/mmH2O/cmH2O/mbar units, 60 mbar/min pressure rate, and touch screen control with LED sample illumination.
TT-CPCT computer controlled carton compression testing machine for ISO 12048 and ASTM D642 box compression tests: test spaces from 80 cm to 150 cm, 0–5000 kg capacities, AC variable frequency or servo drive, switchable kg/lb/N force units, and computerized results recording.
TT-WFODS ocean depth simulation test machine for IEC 60529: water-injection pressurization simulates 100 m or 120 m immersion depth with ±1 to ±2 m control precision, SUS304 tank, 7-inch touch screen, standard and programmable test modes.
TT-DC004 battery extrusion and puncture tester for IEC 62133, UN 38.3 and UL 1642 battery abuse testing: servo motor with screw drive, 1–20 kN extrusion and needle penetration force, 0.1–40 mm/s adjustable speed, SUS304 inner box with explosion-proof design, and PLC touch screen control with voltage and temperature acquisition ports.
TT-GP-ZD1000 electromagnetic vibration test system with VG1000-50 shaker and SA-12 digital switching power amplifier: 1000 kgf peak sine force, 1–3000 Hz frequency range, 51 mm p-p displacement, 100 G maximum acceleration, vertical and horizontal expansion tables, and a two-channel controller with sine and random software.
TT-IE301 connector insertion and extraction force tester with single test station: 0–50 kg force range, 0–80 mm adjustable stroke, 5–60 times/min test speed, up to 999999 settable cycles, and PLC software control with color touch screen and micro thermal printer. Horizontal TT-IE301 and vertical TT-IE301L frames are available.
TT-IPX8PS IPX8 pressure immersion test machine for IEC 60529 and ISO 20653 waterproof testing: transparent plexiglass pressure tank, automatic pressure control with ±0.002 MPa accuracy, 0-999 min timer, and powered-sample terminals for testing samples under working voltage.
TT-BSFJ ice water splash and immersion shock test chamber for ISO 16750-4: upper hot-air zone to 150 °C, lower tank cooled to 0-4 °C, programmed 3 s splash / 29 min 57 s interval cycles, with PID-controlled flow of 3-4 L per 3 s and optional 3% Arizona dust test liquid.
TT-QY102 ball pressure test apparatus for IEC 60695-10-2 heat resistance testing of non-metallic materials: 5 mm pressure ball, 20 N ± 0.2 N load, 125 ± 2 °C heating box, stainless steel specimen holder, for IEC 60335, 60884, 60598 and related product standards.
TT-OATC ozone aging test chamber for rubber ozone cracking tests per ISO 1431, ASTM D1149 and IEC 60811-2-1: 50-1000 pphm ozone concentration, 9-60 °C, static and dynamic strain fixtures with 0.5 Hz cyclic stretching, 1000 L stainless steel chamber.
Our Single Arm Drop Tester is a professional testing instrument designed to simulate free-fall impacts that packages and products may encounter during transportation, shipment, and handling processes. As a reliable single arm drop test machine, it is mainly used to assess the impact degree of product packaging in actual transportation and loading-unloading scenarios, evaluate the impact resistance and durability of packaged goods, and help enterprises optimize packaging design to reduce transportation damage. This single wing drop tester integrates advanced pneumatic control technology and precise height adjustment function, supporting both bare product and packaged product drop tests, which is widely recognized in the field of packaging testing and suitable for various industries’ quality control needs.
