High-low temperature humidity chamber - Professional Environmental Testing Equipment
As a professional manufacturer of environmental testing equipment, we focus on providing high-quality high and low temperature alternating test chambers for global customers. Our products are widely used in electronics, automotive, aerospace, battery, PCB, and other industries, helping you conduct reliable temperature cycling tests to verify the stability and durability of products under extreme temperature conditions.
Product Overview
Our high and low temperature alternating test chamber is a specialized environmental testing device designed to simulate the alternating changes of high and low temperature environments in nature. It can accurately control the temperature range, cycling time, and temperature change rate, enabling your products to undergo rigorous temperature stress tests before leaving the factory. Unlike temperature-humidity cycling chambers, this equipment only controls temperature without humidity regulation, which is more cost-effective and suitable for scenarios that only require temperature cycle testing.
Technical Specifications
| |
|---|
| Optional: -20℃~150℃ / -40℃~150℃ / -60℃~150℃ / -70℃~150℃ |
Temperature Control Accuracy | |
| |
| 1-5℃/min (standard); 5-15℃/min (optional rapid temperature change) |
| 80L, 100L, 150L, 225L, 408L, 800L, 1000L (customizable) |
| |
| Imported Touch Screen Controller (English Interface), Programmable |
| AC 380V/50Hz (customizable according to different countries) |
| Over-temperature, Over-pressure, Power Failure, Compressor Protection |
Core Advantages
- Precise Temperature Control: Equipped with imported temperature controller and high-sensitivity temperature sensor, the temperature control accuracy can reach ±0.5℃, and the temperature fluctuation is ≤±1℃, ensuring the accuracy and repeatability of test data.
- Stable Performance: Adopts high-quality refrigeration compressor and heating system, with fast cooling and heating speed, stable operation, low noise, and long service life. It can continuously work for 24 hours without failure, meeting long-term test needs.
- Flexible Programming: Supports programmable temperature cycling, allowing you to set multiple temperature points, holding time, and temperature change rates (optional 1-15℃/min rapid temperature change), which can be customized according to different test standards and product requirements.
- Humanized Design: The chamber is made of 304 stainless steel, corrosion-resistant and easy to clean; the touch screen operation interface is simple and intuitive, with English display, easy to operate for global users; equipped with over-temperature, over-pressure, and power failure protection functions to ensure the safety of equipment and test samples.
- Cost-Effective Solution: Compared with temperature-humidity alternating test chambers, it has no humidification and dehumidification system, lower production cost, and more favorable price, which can meet your basic temperature cycle test needs at a lower cost.
Reference Standards
Our high and low temperature alternating test chambers fully comply with international and domestic mainstream test standards, ensuring that your test results are authoritative and recognized globally:
- IEC 60068-2-1 (Low Temperature Test)
- IEC 60068-2-2 (High Temperature Test)
- IEC 60068-2-14 (Temperature Change/Temperature Cycling Test)
Key Difference: High and Low Temperature Alternating vs. Temperature-Humidity Alternating Test Chamber
Many customers confuse these two types of equipment. Here is a clear comparison to help you choose the right product:
| High and Low Temperature Alternating Test Chamber | Temperature-Humidity Alternating Test Chamber |
|---|
| | Temperature + Humidity (20%-98%RH) |
| No humidification/dehumidification system | With humidification, dehumidification and condensation control systems |
| More cost-effective (lower) | Higher (usually 20%-40% more expensive) |
| Temperature cycling, high-low temperature storage, temperature shock | Temperature-humidity cycling, damp heat aging, condensation test |
| IEC 60068-2-1, -2, -14; GB/T 2423.1, 2423.2 | IEC 60068-2-78; GB/T 2423.3, 2423.4 |
Application Fields
Our high and low temperature alternating test chambers are widely used in various industries, providing reliable testing support for product quality control:
- Electronics Industry: Testing of electronic components, chips, circuit boards, batteries, etc.
- Automotive Industry: Testing of automotive parts, sensors, batteries, interior materials, etc.
- Aerospace Industry: Testing of aerospace components, instruments, and equipment under extreme temperature conditions.
- Medical Industry: Testing of medical devices, reagents, and materials.
- Plastics & Rubber Industry: Testing of the stability and durability of plastic and rubber products under temperature changes.
Our Service
- Customization Service: We can customize the inner chamber volume, temperature range, temperature change rate, and other parameters according to your specific needs.
- Quality Assurance: All products undergo strict quality inspection before leaving the factory, with a 1-year warranty and lifelong maintenance service.
- Technical Support: Our professional technical team provides 24/7 online support, helping you solve problems in equipment operation and test process.
- Global Shipping: We provide door-to-door shipping service to more than 100 countries and regions, with fast delivery and professional customs clearance assistance.
Frequently Asked Questions (FAQ)
Below are the most common questions from our global customers, if you have other questions not listed here, please contact us directly.
- Q: Can you customize the chamber?
A: Yes, we customize inner volume, temperature range, and temperature change rate as per your needs.
- Q: What is the warranty and after-sales service?
A: 1-year warranty for the whole machine; lifelong maintenance after warranty.
- Q: Do you provide certification (CE, ISO)?
A: Yes, all products have CE and ISO 9001 certifications.
- Q: How to choose the right model?
A: Tell us your test samples, size, and standards, and we will recommend the suitable model.
- Q: What refrigeration system is adopted?
- A: Dual-compressor cascade system (imported), enabling stable -70℃ operation, fast cooling, and automatic defrosting.
- Q: How to ensure temperature uniformity?
- A: Multi-point air circulation and optimized air duct design, with ≤±2℃ uniformity in the effective test area.
